Lot 2

Home "Athader y Proin" 1000/1500/2000 mm. Cross-cutting line for 1500 x 3 steel coils

2 - Cross-cutting line for 1500 x 3 steel coils

Online Auctions

Categories

Share this bid

Manufacturer
ATHADER
Model
J-23
Year
2006
Observations
Transverse cutting line, 1.500x3mm coils.
Material to be processed:
Cold rolled steel, pickling, electro-galvanized and pre-launced;
Tensile strength: 650N/mm2; Elastic limit: 450N/mm2; Maximum coil weight: 25Tn; Bandwidth: 250-1.500mm;
Material thickness: 0.5-3mm; Coil inner diameter: 508-610mm; Outer diameter coil: 800-2.000mm.

MATERIAL TO GET:
Length formats: 250-4.000mm;
Format length with two stacking tables: 8,000mm;
Package weight: 5,000Kg max.; Package height: 600mm.
Sense of work: Right to left;
Processed working speed: 0-65m/min.
Electrical voltage: 400V; 50Hz.

Line consisting of:
Coil storage, cargo cart, unwinder, coil opener, steamroller, cyclic rollers, fast shear and stacked gantry.


No. of items: 1

The lines are dismantled.
