Lot 2

2 - Tube bending machine

Online Auctions

Categories

Share this bid

Manufacturer
Tejero
Model
HC-100 CN
Observations
CNC Fagor 8025 GPI;
Diameter maximum bending (steel 450 N/mm²): 104,0x4,0 mm; Maximum bending (inox. steel 700 N/mm²) diameter: 100,0x1,5 mm; Maximum resistant module (steel 450 N/mm²): 30 cm³;
Radio center curved maximum with pusher: 400 mm;
Maximum bending length: 5.000 mm;
Maximum bending angle: 190 °;
Shaft speed and (curved): 31.1 degrees/s;
Speed of shaft and (reverse): 66.7 degrees/s;
Sense of curved standard: anticlockwise;
Maximum working pressure: 160 bars;
Hydraulic tank capacity: 340 L;
Total installed power: 22, 3 kW;
Central hydraulics; Radial piston, air cooling pump;
Net weight: 5,500 Kg;
Machine dimensions: 7.000 x 1.800 x 1.600 mm;
380V / 50 Hz.



No. of items: 1

Loading on truck for free. Included in the final price.
