Lot 1

Home TRUMPF Trumatic L-3030- 4kw Máquina de corte por láser CO2 - Online auction

1 - Laser cutting machine - 4kW

Online Auctions

Categories

Share this bid

Manufacturer
Trumpf
Model
Trumatic L3030
Year
2002
No. Series
A0220A0092
Observations
 CO2 laser power: 4kW.
Workspace (X x Y x Z): 3,000 x 1,500 x 115mm.
Control: SINUMERIK 840D.
Maximum steel thickness: 20 mm.
Maximum stainless steel thickness: 15mm.
Maximum aluminum thickness: 8mm.
Maximum part weight: 710 kgrs.
Position speed X/Y: 60 m/min. Post speed. Simultaneous: 85 X+Y m/min. With unloading arm.
Laser working hours: 27,200 hrs.
Total machine hours: 53,900hrs.
Consumption: 88kVA, 400V 50Hz.
Weight: 11,500 kg.
Machine exterior dimensions: (length x width x height):
9,300 x 4,600 x 2,000 mm



No. of items: 1

Dismantling and loading costs not included.
