Manufacturer
URPE - ADER SCCL
Model
CC-80
Year
2006
No. Series
109117
Observations
URPE Hot Camera Injector - ADER SCCL CC-80

Maximum Closing Force 960 KN
Mobile Plate Stroke 280 mm
Central extraction force 70 KN
Extraction stroke 70 mm
Thickness molds (min-max.) 160x400 mm
Plate dimension 570x560 mm
Column light 360x360 mm
Column diameter 70 mm
Injection under center plate 0-60 mm
Injection force max. 70 KN
Piston diameter injection 50-55-60 mm
Stroke piston injection 140 mm
Front surface 252-302-362 cm2
Injection volume (DIN24480) 138-188-242 cm3
Specif pressure. Injection 356-294-248 Bar
Desplaz. Closing group 150 mm
Hour cycles DIN24480 1100
Power motor pump 11.5 kW
City gas 24 m3/h
Propane gas 9 Kg/h
Natural gas 12 m3/h
Gas-oíl 9 Kg/h
Electric 18 KW
Crucible capacity 420 Kg
Machine weight 5400 Kg
Dimensions (length x width) 4540x2350 mm
Dimensions (height) 2200 mm



No. of items: 1

Dismantling and loading costs not included.
