1 - Metal roll forming machine

Online Auctions

Categories

Share this bid

Manufacturer
Diper
Model
625MM
Year
1995
Observations
Galvanized or pre-lacquered steel coil sheet profiler.
Intended to produce door slat profile.
Includes unwinder 2 T., and side bench for finished product:
• Useful profile width: 540 mm
• Trapezoid height: 14 mm
• Max thickness: 0.8 mm
GENERAL CHARACTERISTICS:
• Feed sense: left > right
• Speed: 15 m/min.
• Total power: 15 Kw (approx.)
• Max. sheet width: 625 mm
• Overall dimensions: 5,000 x 1,800 mm
TECHNICAL SPECIFICATIONS:
• Head number: left > right
• Motor power: 4 Kw
• Working axles: or Quality: F-125 or Ø: 60 mm
• Forming rollers: F-522 (treated)
• Max width: 625 mm
• Length of the sheet: 5.000 mm



No. of items: 1

Dismantling and loading costs not included.
