Home Centro de mecanizado CNC - HAAS VF-7/50 CNC Vertical machining center
ManufacturerHaas ModelVF-7/50 Year2016 Observations
Travels
X axis 2134 mm
Axle Y 813 mm
Z-axis 762 mm
Spindle nose to table (max.) 889 mm
Spindle nose to table (min.) 127 mm
SPINDLE
Power max. 22.4 Kw
Speed max. 7500 rpm
Torque max. 460 Nm x 700 rpm
Drive system 2-Speed Gearbox
Ct cone or BT 50
Air/ Oil Injection Bearing Lubrication
Cooled Liquid Cooling
table
Max length. tool (from calibration line) 2134 mm
Width 711 mm
Slots width in T 16 mm
Wheelbase with T-slot 125mm
Number of standard T-slots
Max weight. on table (evenly distributed) 1814 kg
FEEDRATES
Maximum cut 12.7 m/min
Fast in X 15.2 m/min
Fast in Y 15.2 m/min
Fast Z 15.2 m/min
AXIS MOTORS
Thrust max. X 15124 N
Thrust max. And 18238 N
Thrust max. Z 24910 N
TOOL CHANGER
Type SMTC
Coolant capacity 30+1
Diameter max. tool (occupied) 102 mm
Diameter max. tool (empty contiguous) 254 mm
Max length. tool (from calibration line) 406 mm
Max weight. tool 13.6 kg
Tool to tool (medium) 4.2 sec
Chip to chip (medium) 6.3 sec
GENERAL FEATURES
Coolant capacity 360 L
AIR REQUIREMENTS
Air required 113 L/min x 6.9 bar
Inlet air hose 3/8 in.
Coupler (air) 3/8 in
Min. air pressure 5.5 bar
DIMENSIONS - SHIPPING
household palette with option EC 544 cm x 260 cm x 336 cm
Export box with option EC 544 cm x 270 cm x 346 cm
Weight 12021.0 kg
household palette with option EC 544 cm 260 cm 356 cm
EC-option export box
Weight with option EC 544 cm 270 cm 366 cm
ELECTRICAL SPECIFICATION
Spindle speed 7500 rpm
Drive system 2-Speed Gearbox
Spindle power 22.4 kW
AC input voltage (3 phase) - Low 220 VAC
Ampere full load (3 phase) - Under 70 A
AC input voltage (3 phase) - High 440 VAC
Ampere full charge (3 phase) - High 35 A
No. of items: 1
costes de desmontaje y carga no incluidos
