Gutinvest

Lot 3

3 - CNC punching machine

Online Auctions

CLOSED

Categories

Share this bid

Manufacturer
SHIAVI
Model
VULCANO K-7512
Year
20066
Observations
Maximum force: 28 tons;
Stations: 1;
Number of tools: 10;
Max diameter with punch: 88.9mm;
Useful working field: 750x1250mm;
Maximum thickness of the sheet metal: 6.4 mm;
Maximum length of the sheet metal: 750 mm;
Maximum width of the sheet metal: 1250 mm;
Maximum punching speed: 300 per minute;
Max weight sheet metal: 60kg;
Axis speed: 30m / min;
Number of clamps: 2;
Max power installed: 10kW;
Machine weight: 3,800Kg.


No. of items: 1

Dismantling and loading costs not included.
