Gutinvest

Lot 2

Home DYE FPF-4-NC / RAMBAUDI Ramspeed H-45L Gantry cnc milling machine - 5 axes

2 - Gantry cnc milling machine - 5 axes

Online Auctions

Categories

Share this bid

Manufacturer
Rambaudi
Model
Ramspeed H45L
Year
1998
Observations
Technical data:
 Controller: NUM
Model: PCNC 1060 MSI
Measurements width  6046 mm
Measurements depth 2700 mm
Measurements height 5490 mm
Machine weight 40.000 Kgrs.
Number of spindles 1
Spindle speed range 3000 rpm
X-Axis Movement 4500 mm
Y-Axis Movement 2500 mm
Z-Axis Movement 1250 mm
Workpiece X 4500 mm
Workpiece Y 2500 mm
Workpiece Z 1250 mm
Outer length 5000 mm
Outer width 2500 mm
Number of tslots 10
Slots in storage 6
Max weight 2 kg
Max tool length 300 mm
Working area: 4.500 x 2.700 x 1.500 mm.



No. of items: 1

Dismantling and loading costs not included.
