No. of sale: 101219T
Starting date
ManufacturerJeanologia ModelNano shop Year2016 No. SeriesNANO-0083 ObservationsTECHNICAL SPECIFICATIONS :
LASER SOURCE: CO2 sealed cavity, RF discharge excitation; Wavelength: 10.6um; Pulse frequency: up to 25kHz; Output Power: 30W; Maximum power: 50W; Beam size: 1.8+-0.2mm.
ENERGY SOURCES: Voltage: 115-230V, single phase, 50/60Hz; Power: 1000W; consumption: 6,22A(230V) or 12.5A (115V);
PERFORMANCE PARAMETERS: Marking window: 150x150mm (For a 225 focal lens); Target substrate: Textile fabrics 8vaqueras, leather...), wallpaper. Two-position on/off switch (On/Off); Two-position laser source disconnect wrench (0/1). Withdrawal only in position 0; Open/closed two-position shutter wrench). Withdrawal only possible in closed position; Light indicators: Laser emission, alarm, external contact opening, ignition, power supply and sealing status.
PRINT FUNCTIONS: Bitmap (BMP); Vector Images (DXF); Fixed texts in all fonts, rotation angles, variable font size; Curves, rectangles, circles, ellipses, and polygons; Clipart.
MACHINE DEIMENSIONS: 1.500X900X500mm;
Machine weight: 175Kg; Power cable length: 2 meters.
ManufacturerJeanologia ModelNano shop Year2016 No. SeriesNANO-0083 ObservationsTECHNICAL SPECIFICATIONS :
LASER SOURCE: CO2 sealed cavity, RF discharge excitation; Wavelength: 10.6um; Pulse frequency: up to 25kHz; Output Power: 30W; Maximum power: 50W; Beam size: 1.8+-0.2mm.
ENERGY SOURCES: Voltage: 115-230V, single phase, 50/60Hz; Power: 1000W; consumption: 6,22A(230V) or 12.5A (115V);
PERFORMANCE PARAMETERS: Marking window: 150x150mm (For a 225 focal lens); Target substrate: Textile fabrics 8vaqueras, leather...), wallpaper. Two-position on/off switch (On/Off); Two-position laser source disconnect wrench (0/1). Withdrawal only in position 0; Open/closed two-position shutter wrench). Withdrawal only possible in closed position; Light indicators: Laser emission, alarm, external contact opening, ignition, power supply and sealing status.
PRINT FUNCTIONS: Bitmap (BMP); Vector Images (DXF); Fixed texts in all fonts, rotation angles, variable font size; Curves, rectangles, circles, ellipses, and polygons; Clipart.
MACHINE DEIMENSIONS: 1.500X900X500mm;
Machine weight: 175Kg; Power cable length: 2 meters.
Estimation 25.000 - 27.500 €
Start price 0 €
ManufacturerGEMfix ModelSTRASSBOX PRO (4 colores) Year2016 ObservationsAutomatic machine for the production of transfer of stones, studs and others;
Features: -
4 sizes or 4 colors in the same design.
Max. Speed: 190From SS 6 (2mm) until SS 20 (5mm). rhinestones per minute.
Maximum working field: 500mmx320mm.
Type
Arm type mode
Working area
500mm x 320 mm
Memory
Unlimited (pc / laptop not included)
Production Rate (stones per minute)
190spm (max speed)
Rhinestone Size
From SS6 (2mm) to SS20 (5mm) - option until SS45 (10mm)
Rhinestone Feeder
4 Colors or Sizes
Cylinder Rotation
Step motor / Software regulation
Dimensions ( without / with box)
760 x 800 x 380mm / 1200 x 900 x 800mm
Compressor(liters per minute)
100 liters/minute
ManufacturerGEMfix ModelSTRASSBOX PRO (4 colores) Year2016 ObservationsAutomatic machine for the production of transfer of stones, studs and others;
Features: -
4 sizes or 4 colors in the same design.
Max. Speed: 190From SS 6 (2mm) until SS 20 (5mm). rhinestones per minute.
Maximum working field: 500mmx320mm.
Type
Arm type mode
Working area
500mm x 320 mm
Memory
Unlimited (pc / laptop not included)
Production Rate (stones per minute)
190spm (max speed)
Rhinestone Size
From SS6 (2mm) to SS20 (5mm) - option until SS45 (10mm)
Rhinestone Feeder
4 Colors or Sizes
Cylinder Rotation
Step motor / Software regulation
Dimensions ( without / with box)
760 x 800 x 380mm / 1200 x 900 x 800mm
Compressor(liters per minute)
100 liters/minute
Estimation 9.500 - 10.500 €
Start price 0 €
