No. of sale: 111219M
Starting date
ManufacturerATHADER ModelJ-26 Year2001 ObservationsMaximum band coil cutting line: 2000 X 6mm.
Processing speed 150 mts/min - 75 mts/min.
Tensile strength: 500N/mm2; Elastic limit: 400N/mm2; Maximum coil weight: 30Tn; Bandwidth: 500-2.000mm;
Material thickness: 1.5-6mm;
Coil inner diameter: 508-610/760mm;
Outer diameter coil: 850-2.000mm.
MATERIAL TO OBTAIN:
Bandwidth: 30 to 2,000mm; Maximum coil weight: 30Tn;
Inner coil diameter: 508/610mm;
Outer diameter coil: 850-2.000mm; Thickness 3-6mm.
Electrical voltage: 380V; 50Hz.
ManufacturerATHADER ModelJ-26 Year2001 ObservationsMaximum band coil cutting line: 2000 X 6mm.
Processing speed 150 mts/min - 75 mts/min.
Tensile strength: 500N/mm2; Elastic limit: 400N/mm2; Maximum coil weight: 30Tn; Bandwidth: 500-2.000mm;
Material thickness: 1.5-6mm;
Coil inner diameter: 508-610/760mm;
Outer diameter coil: 850-2.000mm.
MATERIAL TO OBTAIN:
Bandwidth: 30 to 2,000mm; Maximum coil weight: 30Tn;
Inner coil diameter: 508/610mm;
Outer diameter coil: 850-2.000mm; Thickness 3-6mm.
Electrical voltage: 380V; 50Hz.
Start price 350.000 €
ManufacturerATHADER ModelJ-23 Year2006 ObservationsTransverse cutting line, 1.500x3mm coils.
Material to be processed:
Cold rolled steel, pickling, electro-galvanized and pre-launced;
Tensile strength: 650N/mm2; Elastic limit: 450N/mm2; Maximum coil weight: 25Tn; Bandwidth: 250-1.500mm;
Material thickness: 0.5-3mm; Coil inner diameter: 508-610mm; Outer diameter coil: 800-2.000mm.
MATERIAL TO GET:
Length formats: 250-4.000mm;
Format length with two stacking tables: 8,000mm;
Package weight: 5,000Kg max.; Package height: 600mm.
Sense of work: Right to left;
Processed working speed: 0-65m/min.
Electrical voltage: 400V; 50Hz.
Line consisting of:
Coil storage, cargo cart, unwinder, coil opener, steamroller, cyclic rollers, fast shear and stacked gantry.
ManufacturerATHADER ModelJ-23 Year2006 ObservationsTransverse cutting line, 1.500x3mm coils.
Material to be processed:
Cold rolled steel, pickling, electro-galvanized and pre-launced;
Tensile strength: 650N/mm2; Elastic limit: 450N/mm2; Maximum coil weight: 25Tn; Bandwidth: 250-1.500mm;
Material thickness: 0.5-3mm; Coil inner diameter: 508-610mm; Outer diameter coil: 800-2.000mm.
MATERIAL TO GET:
Length formats: 250-4.000mm;
Format length with two stacking tables: 8,000mm;
Package weight: 5,000Kg max.; Package height: 600mm.
Sense of work: Right to left;
Processed working speed: 0-65m/min.
Electrical voltage: 400V; 50Hz.
Line consisting of:
Coil storage, cargo cart, unwinder, coil opener, steamroller, cyclic rollers, fast shear and stacked gantry.
Start price 450.000 €
ManufacturerATHADER Modelmod. LCT-1003/15T/3M (J21) Year2001 ObservationsTransverse cutting line, 1.000x3mm coils.
Material to be processed:
Cold rolled steel coils; Tensile strength: 45Kg/mm2;
Maximum coil weight: 15Tn;
Maximum bandwidth: 1,050mm; Minimum bandwidth: 250mm;
Material thickness: 0.5/3mm; Inner coil diameter: 508/610mm; Outer diameter coil: 1.000/1.800mm.
MATERIAL TO OBTAIN:
Flattened and stacked formats;
Min.format length: 250mm; Max.format length: 3,000mm; Material thickness: 0.5/3mm;
Maximum package weight: 3,000Kg. Working sense: Right-Left; Working speed: Adjustable from 0 to 90 mts/min.
Electrical voltage: 110-380V; 50Hz.
Line composed of:
Coil storage, loading trolley, unwinder, coil opener, flattening, pit entry and exit, cyclic roller, guillotine, pitch table and stacker.
ManufacturerATHADER Modelmod. LCT-1003/15T/3M (J21) Year2001 ObservationsTransverse cutting line, 1.000x3mm coils.
Material to be processed:
Cold rolled steel coils; Tensile strength: 45Kg/mm2;
Maximum coil weight: 15Tn;
Maximum bandwidth: 1,050mm; Minimum bandwidth: 250mm;
Material thickness: 0.5/3mm; Inner coil diameter: 508/610mm; Outer diameter coil: 1.000/1.800mm.
MATERIAL TO OBTAIN:
Flattened and stacked formats;
Min.format length: 250mm; Max.format length: 3,000mm; Material thickness: 0.5/3mm;
Maximum package weight: 3,000Kg. Working sense: Right-Left; Working speed: Adjustable from 0 to 90 mts/min.
Electrical voltage: 110-380V; 50Hz.
Line composed of:
Coil storage, loading trolley, unwinder, coil opener, flattening, pit entry and exit, cyclic roller, guillotine, pitch table and stacker.
Start price 150.000 €
ManufacturerPROIN Year1989 ObservationsCross-sectional line, 1500X3mm band coils.
Max.band width: 1,500mm; Min. bandwidth band: 400mm;
Materials to be processed:
Cold/Decapado; Thickness: 1.5-6mm;
Inner diameter: 508/750mm; Maximum Diameter: 2,000mm; Maximum Weight: 20 tm;
Speed: 30/40 min;
Maximum package weight: 5 tm; Format: up to 8 meters.
Line composed of:
Lifting table, coil load holder, tip drag, centering roller, flattener, guillotine, guillotine output rollers and stacker.
ManufacturerPROIN Year1989 ObservationsCross-sectional line, 1500X3mm band coils.
Max.band width: 1,500mm; Min. bandwidth band: 400mm;
Materials to be processed:
Cold/Decapado; Thickness: 1.5-6mm;
Inner diameter: 508/750mm; Maximum Diameter: 2,000mm; Maximum Weight: 20 tm;
Speed: 30/40 min;
Maximum package weight: 5 tm; Format: up to 8 meters.
Line composed of:
Lifting table, coil load holder, tip drag, centering roller, flattener, guillotine, guillotine output rollers and stacker.
Start price 75.000 €
