No. of sale: 140519M
Starting date
ManufacturerTejero ModelH-42 CNC Year2004 No. Series210 ObservationsHydraulic bending machine 3 controlled axes.
Control "Side" and "Wintej" program.
Capacity: up to tube 42 m/m.
Capacity for curved by generation up to 32 m/m.
Available array of double height.
Revised in perfect condition and in accordance with regulations CE machine.
Few working hours.
ManufacturerTejero ModelH-42 CNC Year2004 No. Series210 ObservationsHydraulic bending machine 3 controlled axes.
Control "Side" and "Wintej" program.
Capacity: up to tube 42 m/m.
Capacity for curved by generation up to 32 m/m.
Available array of double height.
Revised in perfect condition and in accordance with regulations CE machine.
Few working hours.
Start price 25.000 €
ManufacturerTejero ModelHC-100 CN ObservationsCNC Fagor 8025 GPI;
Diameter maximum bending (steel 450 N/mm²): 104,0x4,0 mm; Maximum bending (inox. steel 700 N/mm²) diameter: 100,0x1,5 mm; Maximum resistant module (steel 450 N/mm²): 30 cm³;
Radio center curved maximum with pusher: 400 mm;
Maximum bending length: 5.000 mm;
Maximum bending angle: 190 °;
Shaft speed and (curved): 31.1 degrees/s;
Speed of shaft and (reverse): 66.7 degrees/s;
Sense of curved standard: anticlockwise;
Maximum working pressure: 160 bars;
Hydraulic tank capacity: 340 L;
Total installed power: 22, 3 kW;
Central hydraulics; Radial piston, air cooling pump;
Net weight: 5,500 Kg;
Machine dimensions: 7.000 x 1.800 x 1.600 mm;
380V / 50 Hz.
ManufacturerTejero ModelHC-100 CN ObservationsCNC Fagor 8025 GPI;
Diameter maximum bending (steel 450 N/mm²): 104,0x4,0 mm; Maximum bending (inox. steel 700 N/mm²) diameter: 100,0x1,5 mm; Maximum resistant module (steel 450 N/mm²): 30 cm³;
Radio center curved maximum with pusher: 400 mm;
Maximum bending length: 5.000 mm;
Maximum bending angle: 190 °;
Shaft speed and (curved): 31.1 degrees/s;
Speed of shaft and (reverse): 66.7 degrees/s;
Sense of curved standard: anticlockwise;
Maximum working pressure: 160 bars;
Hydraulic tank capacity: 340 L;
Total installed power: 22, 3 kW;
Central hydraulics; Radial piston, air cooling pump;
Net weight: 5,500 Kg;
Machine dimensions: 7.000 x 1.800 x 1.600 mm;
380V / 50 Hz.
Start price 22.000 €
