No. of sale: 210121C
Starting date
ManufacturerAX ModelAX-5 Year2020 ObservationsCONTINUOUS POWER 4600 w MAXIMUM POWER 5000 w MAXIMUM POWER 20 amp VOLTAGE 2x230 Vac OUTPUT DC 12V/8.3A POWER FACTOR 1.0 (lag) DIMENSIONS AND LONG WEIGHT 950 mm WIDTH 570 mm HIGH 860 mm WEIGHT95 kg CONTROL SPACE 2x230 Vac (2 ENCHUFES) 1 VOLTMETER Built-in 1 INTERRUPTOR OFF/ON Built-in OVERVOLTAGE PROTECTION Engine TYPE MOTOR 1 Cylinder, 4-time AIR COOLING REVOLUTIONS 3,000 rpm CILINDRATED 418 c.c. DIESEL TYPE OIL SAE 10W30 ELECTRIC ERTER Built-in CAPACITY GASOIL DEPOSIT 11.5 L FUEL DIESEL A * FUNCTIONALITIES DURATION USE WITH FULL TANK 7.3 h. NOISE 89 dB ELECTRIC START Plus battery ALARM LACK OF OIL Built-in WHEELS Built-in OUTPUT POWERS 230+12 V CERTIFICATES CE, GS, TUV. CONTINUOUS POWER 50 Hz.
ManufacturerAX ModelAX-5 Year2020 ObservationsCONTINUOUS POWER 4600 w MAXIMUM POWER 5000 w MAXIMUM POWER 20 amp VOLTAGE 2x230 Vac OUTPUT DC 12V/8.3A POWER FACTOR 1.0 (lag) DIMENSIONS AND LONG WEIGHT 950 mm WIDTH 570 mm HIGH 860 mm WEIGHT95 kg CONTROL SPACE 2x230 Vac (2 ENCHUFES) 1 VOLTMETER Built-in 1 INTERRUPTOR OFF/ON Built-in OVERVOLTAGE PROTECTION Engine TYPE MOTOR 1 Cylinder, 4-time AIR COOLING REVOLUTIONS 3,000 rpm CILINDRATED 418 c.c. DIESEL TYPE OIL SAE 10W30 ELECTRIC ERTER Built-in CAPACITY GASOIL DEPOSIT 11.5 L FUEL DIESEL A * FUNCTIONALITIES DURATION USE WITH FULL TANK 7.3 h. NOISE 89 dB ELECTRIC START Plus battery ALARM LACK OF OIL Built-in WHEELS Built-in OUTPUT POWERS 230+12 V CERTIFICATES CE, GS, TUV. CONTINUOUS POWER 50 Hz.
Start price 1.350 €
ManufacturerAX ModelAX-15 Year2020 ObservationsMAIN FEATURES MODEL AX-15 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 12 kW/ 15 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 21.6 amp FREQUENCY 50 Hz ALTERNATOR NOMINAL POWER 12 kW VOLTAGE 400 V PHASES 3 POWER FACTOR 0.8 (lag) NOMINAL CURRENT 21.6 a. REVOLUTIONS 1,500 R FREQUENCY 50 Hz CLASS STANFORD Brushless (brushless) DIMENSIONS AND LONG WEIGHT 1,900 mm WIDTH 1,000 mm HIGH 1,100 mm WEIGHT 586 kg AVERAGE CONSUMPTION STIPULATED AT 100% RPM 4.2 L/h AL75% RPM 3.1 L/h AT 50% RPM 2.4 L/h AT 25% RPM 1.6 L/h CAPACITY DEPOSIT GASOIL 72 L ENGINE AX 2110D DIéSEL. RICARDO LINE NOMINAL POWER 19.5 kW POWER. OVERLOAD 21.45/1.500r FREQUENCY RPM 1,500 CYLINDERS No. 2 DIAMETER PISTON 110*117 mm METHOD ADJUSTMENT Machine MAX. VELO. NO CHARGE IS 1575 r/min REFRIGERATION WATER Circuit START Battery 12v or ATS SYSTEM MODE COMBUSTION Direct Injection Camera ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT WATER COOLED ≤95oC CAPA ...
ManufacturerAX ModelAX-15 Year2020 ObservationsMAIN FEATURES MODEL AX-15 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 12 kW/ 15 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 21.6 amp FREQUENCY 50 Hz ALTERNATOR NOMINAL POWER 12 kW VOLTAGE 400 V PHASES 3 POWER FACTOR 0.8 (lag) NOMINAL CURRENT 21.6 a. REVOLUTIONS 1,500 R FREQUENCY 50 Hz CLASS STANFORD Brushless (brushless) DIMENSIONS AND LONG WEIGHT 1,900 mm WIDTH 1,000 mm HIGH 1,100 mm WEIGHT 586 kg AVERAGE CONSUMPTION STIPULATED AT 100% RPM 4.2 L/h AL75% RPM 3.1 L/h AT 50% RPM 2.4 L/h AT 25% RPM 1.6 L/h CAPACITY DEPOSIT GASOIL 72 L ENGINE AX 2110D DIéSEL. RICARDO LINE NOMINAL POWER 19.5 kW POWER. OVERLOAD 21.45/1.500r FREQUENCY RPM 1,500 CYLINDERS No. 2 DIAMETER PISTON 110*117 mm METHOD ADJUSTMENT Machine MAX. VELO. NO CHARGE IS 1575 r/min REFRIGERATION WATER Circuit START Battery 12v or ATS SYSTEM MODE COMBUSTION Direct Injection Camera ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT WATER COOLED ≤95oC CAPA ...
Start price 4.500 €
ManufacturerAX ModelAX-50 Year2020 ObservationsMAIN FEATURES MODEL AX-50 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 40 kW/ 50 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 72 amp FREQUENCY 50 Hz
DIMENSIONS LONG 2,200 xWIDTH 1,000 mm x HIGH 1.200 mm WEIGHT 836 kg
AVERAGE CONSUMPTION STIPULATED AT 100% RPM 13.2 L/h AL 75% RPM 10.4 L/h AL 50% RPM 8 L/h AT 25% RPM 5.5 L/h CAPACITY DEPOSIT GASOIL 84 L
ENGINE AX 4100 ZD DIéSEL.
RICARDO LINE NOMINAL POWER 41.5 kW EXHAUST TEMPERATURE ≤470oC FREQUENCY RPM 1,500 CYLINDERS No. 4 DIAMETER PISTON 110*115 mm METHOD ADJUSTMENT Machine MAX. VELO. NO LOAD IS 1,575 r/min
REFRIGERATION WATER circuit START Battery 12v or ATS SYSTEM COMBUSTION MODE Direct Injection CAMERA ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT COOLED WATER ≤90oC CAPACITY OIL 12 L LEFT CRANKSHAFT ROTATION MOTOR TYPE Ref. By water, 4 times DISPLACEMENT 3,610 L TYPE TOP OIL 15W40 COMPRESSION 19 to 1 POWER JUMPS 1-3-4-2 MINIMUM IDLING E ...
ManufacturerAX ModelAX-50 Year2020 ObservationsMAIN FEATURES MODEL AX-50 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 40 kW/ 50 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 72 amp FREQUENCY 50 Hz
DIMENSIONS LONG 2,200 xWIDTH 1,000 mm x HIGH 1.200 mm WEIGHT 836 kg
AVERAGE CONSUMPTION STIPULATED AT 100% RPM 13.2 L/h AL 75% RPM 10.4 L/h AL 50% RPM 8 L/h AT 25% RPM 5.5 L/h CAPACITY DEPOSIT GASOIL 84 L
ENGINE AX 4100 ZD DIéSEL.
RICARDO LINE NOMINAL POWER 41.5 kW EXHAUST TEMPERATURE ≤470oC FREQUENCY RPM 1,500 CYLINDERS No. 4 DIAMETER PISTON 110*115 mm METHOD ADJUSTMENT Machine MAX. VELO. NO LOAD IS 1,575 r/min
REFRIGERATION WATER circuit START Battery 12v or ATS SYSTEM COMBUSTION MODE Direct Injection CAMERA ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT COOLED WATER ≤90oC CAPACITY OIL 12 L LEFT CRANKSHAFT ROTATION MOTOR TYPE Ref. By water, 4 times DISPLACEMENT 3,610 L TYPE TOP OIL 15W40 COMPRESSION 19 to 1 POWER JUMPS 1-3-4-2 MINIMUM IDLING E ...
Start price 5.750 €
ManufacturerAX ModelAX-100 Year2020 ObservationsMAIN FEATURES MODEL AX-100 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 88 kW/ 100 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 144 amp FREQUENCY 50 Hz DIMENSIONS AND LONG WEIGHT 3,000 mm WIDTH 1,100 mm HIGH 1,400 mm WEIGHT 1,365 kg AVERAGE CONSUMPTION STIPULATED AT 100% RPM 25 L/h AT 75% RPM 19.7 L/h AT 50% RPM 14.6 L/h AT 25% RPM 9.88 L/h CAPACITY GASOIL DEPOSIT 130 L ENGINE AX 6105AZD DIéSEL. RICARDO LINE NOMINAL POWER 88 kW EXHAUST TEMPERATURE ≤600oC FREQUENCY RPM 1,500 CYLINDERS No. 6 DIAMETER PISTON 105*130 mm METHOD ADJUSTMENT Machine MAX. VELO. NO CHARGE IS 1,575 r/min REFRIGERATION WATER Circuit START Battery 24v or ATS SYSTEM COMBUSTION MODE Direct Injection Camera ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT COOLED WATER ≤90oC CAPACITY OIL 22.1 L LEFT CRANKSHAFT ROTATION TYPE MOTOR Ref. By Water, 4-Time DISPLACEMENT 6,490 L TYPE TOP OIL 15W40 COMPRESSION 17 to 1 POWER JUMPS 1-5-3-6-2-4 RALE ...
ManufacturerAX ModelAX-100 Year2020 ObservationsMAIN FEATURES MODEL AX-100 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 88 kW/ 100 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 144 amp FREQUENCY 50 Hz DIMENSIONS AND LONG WEIGHT 3,000 mm WIDTH 1,100 mm HIGH 1,400 mm WEIGHT 1,365 kg AVERAGE CONSUMPTION STIPULATED AT 100% RPM 25 L/h AT 75% RPM 19.7 L/h AT 50% RPM 14.6 L/h AT 25% RPM 9.88 L/h CAPACITY GASOIL DEPOSIT 130 L ENGINE AX 6105AZD DIéSEL. RICARDO LINE NOMINAL POWER 88 kW EXHAUST TEMPERATURE ≤600oC FREQUENCY RPM 1,500 CYLINDERS No. 6 DIAMETER PISTON 105*130 mm METHOD ADJUSTMENT Machine MAX. VELO. NO CHARGE IS 1,575 r/min REFRIGERATION WATER Circuit START Battery 24v or ATS SYSTEM COMBUSTION MODE Direct Injection Camera ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT COOLED WATER ≤90oC CAPACITY OIL 22.1 L LEFT CRANKSHAFT ROTATION TYPE MOTOR Ref. By Water, 4-Time DISPLACEMENT 6,490 L TYPE TOP OIL 15W40 COMPRESSION 17 to 1 POWER JUMPS 1-5-3-6-2-4 RALE ...
Start price 7.900 €
ManufacturerAX ModelAX-200 Year2020 ObservationsMAIN FEATURES MODEL AX-200 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 160 kW/ 200 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 288 amp FREQUENCY 50 Hz DIMENSIONS AND LONG WEIGHT 3,500 mm WIDTH 1,250 mm HIGH 1.250 mm 860 mm WEIGHT 1,815 kg ALTERNATOR NOMINAL POWER 160 kW VOLTAGE 400/220 V PHASES 3 POWER FACTOR 0.8 (lag) NOMINAL CURRENT 360 a. REVOLUTIONS 1,500 R FREQUENCY 50 Hz STANFORD Brushless CLASS (brushless) AX 6126AZLD DIESEL ENGINE. RICARDO LINE NOMINAL POWER 180 kW EXHAUST TEMPERATURE ≤660oC FREQUENCY RPM 1,500 CYLINDERS No. 6 DIAMETER PISTON 126*130 mm METHOD ADJUSTMENT Machine MAX. VELO. NO CHARGE IS 1,500 r/min REFRIGERATION Closed water circuit ELECTRIC START (sist. OPTIONAL ATS) COMBUSTITION MODE Direct Injection Camera ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT COOLED WATER ≤90oC CAPACITY OIL 56 L LEFT ROTATION TYPE MOTOR Ref. BY water, 4 times DISPLACEMENT 10.1 L TYPE OIL YOUR ...
ManufacturerAX ModelAX-200 Year2020 ObservationsMAIN FEATURES MODEL AX-200 NOMINAL VOLTAGE 400/220 V R POWER FACTOR 0.8 (lag) NOMINAL POWER 160 kW/ 200 kVA REVOLUTIONS 1,500 rpm NOMINAL CURRENT 288 amp FREQUENCY 50 Hz DIMENSIONS AND LONG WEIGHT 3,500 mm WIDTH 1,250 mm HIGH 1.250 mm 860 mm WEIGHT 1,815 kg ALTERNATOR NOMINAL POWER 160 kW VOLTAGE 400/220 V PHASES 3 POWER FACTOR 0.8 (lag) NOMINAL CURRENT 360 a. REVOLUTIONS 1,500 R FREQUENCY 50 Hz STANFORD Brushless CLASS (brushless) AX 6126AZLD DIESEL ENGINE. RICARDO LINE NOMINAL POWER 180 kW EXHAUST TEMPERATURE ≤660oC FREQUENCY RPM 1,500 CYLINDERS No. 6 DIAMETER PISTON 126*130 mm METHOD ADJUSTMENT Machine MAX. VELO. NO CHARGE IS 1,500 r/min REFRIGERATION Closed water circuit ELECTRIC START (sist. OPTIONAL ATS) COMBUSTITION MODE Direct Injection Camera ADVANCE ANGLE GASOIL SUPPLY 17±1o TEMPERATURE OUTPUT COOLED WATER ≤90oC CAPACITY OIL 56 L LEFT ROTATION TYPE MOTOR Ref. BY water, 4 times DISPLACEMENT 10.1 L TYPE OIL YOUR ...
Start price 13.950 €
