No. of sale: 250719E
Starting date
ManufacturerSIEMENS GAMESA ModelEIOLICA SEVI ObservationsProcess description: SEVI is a semi-automatic system to assemble part of the shovel G128 beam. Beam are four pieces of 30 meters. The parts are loaded with a crane. They are fastened with suction cups and mechanical moorings. Operators apply adhesive. The system uses computer vision to calculate the required position. And assemble the pieces moving each motor to the calculated position. Then use air heaters to cure the adhesive. Main parts of the line: parts clamping systems: pneumatic moorings of templates. Suction cups and vacuum system (venturis and pumps). Mechanical moorings. Parts movement systems: spin webs: spindle motors. Superior ability to spin: axis of rotation motors. Translation capacity: the towers are moved by rail. Adjust position websites and superior ability: spindle motors. Machine vision system: 28 cameras and LED lights. Software to recognize the gap between parts. Curing system: 8 heater. Tubes and gutter. Control system of curing adhesive (with thermocouples). Detection: Presence of parts. Position handrails and stairs that can interfere with movement.
ManufacturerSIEMENS GAMESA ModelEIOLICA SEVI ObservationsProcess description: SEVI is a semi-automatic system to assemble part of the shovel G128 beam. Beam are four pieces of 30 meters. The parts are loaded with a crane. They are fastened with suction cups and mechanical moorings. Operators apply adhesive. The system uses computer vision to calculate the required position. And assemble the pieces moving each motor to the calculated position. Then use air heaters to cure the adhesive. Main parts of the line: parts clamping systems: pneumatic moorings of templates. Suction cups and vacuum system (venturis and pumps). Mechanical moorings. Parts movement systems: spin webs: spindle motors. Superior ability to spin: axis of rotation motors. Translation capacity: the towers are moved by rail. Adjust position websites and superior ability: spindle motors. Machine vision system: 28 cameras and LED lights. Software to recognize the gap between parts. Curing system: 8 heater. Tubes and gutter. Control system of curing adhesive (with thermocouples). Detection: Presence of parts. Position handrails and stairs that can interfere with movement.
Start price 500.000 €
