No. of sale: 311019M
Starting date
ManufacturerTrumpf ModelL-3030 Year2003 ObservationsLaser Cutting Trumpf TCL 3030 - 4000W + LiftMaster
Working area: XxYxZ [mm]: 3000x1500x115 mm.
Control: Siemens Sinumerik 840 D Laser-Type: CO2 TLF 4000 turbo
Operating hours: 93.980/69.877h;
Power: 4000W CNC Laser Output [Watt]: 190-4000
Max. Workpiece Weight [kg]: 710
Max. Material Thickness (mild steel) [mm]: 20 Max.
Material Thickness (stainless steel) [mm]: 15 Max.
Material Thickness (aluminum) [mm]: 10 Max.
Positioning Speed [m/min.]: axis-parallel / simultaneous (Х и Y): 60/84
Consumption values laser gas: CO2 - 1,0 l/h; N2 - 6,0 l/h; He - 13,0 l/h Compressed air consumption: 7-9 bar, 31 m3 /h 720 l/min
Electric connection: 33-67 kW / 88 kVA / 400W (± 10%) / 50Hz (± 1%) / 3 Phase / 160 A.
Dimensions machine: L/W/H [mm]: 9800/4600/2000;
Weight [kg]: 11500.
Standard equipment:
-Closed machine frame with integrated laser unit.
-Motion unit for high precision processing.
-Drives with maintenance-free servo motors.
-Enclosed beam delivery system, -Mirror telescope,-Automatic pallet changer, -Conveyor belt for small parts / slug, -TFT colour screen, -Work area lighting,-Machine up to 43 o ambient temperature, -AutoLas Plus -HI-LAS® -PlasmaLine PMS plasma sensor -SprintLine® -ContourLine® -Programmable cutting gas pressure: TRUMPF Laser: -CO2-Laser TLF 4000 turbo, -Radio-frequency excitation, -Laser control TASC, -Laser power control -Logbook function laser Cutting head: -Laser cutting head with 5 zoll lens -Laser cutting head with 7,5 zoll lens -Cutting head quick-change device -Capacitive height regulation (DIAS III) Digitales Intelligentes Abstands-System -Spray Control:- Open control PC-based, simple operation and networking -Online-Help: -Diagnostic functions: -Logbook function -Technology data -Teleservice -Shutdown -Position laser diode -Workshop programming ToPs 100 lite Data transmission: -Network connection -BNC-/ RJ 45 network connector -3.5 Floppy Drive -MDE interface Safety: -CE label: -Light barrier: -Multi chamber exhaust system -Compact dust extractor-Machine enclosure with Macrolon panels -Monitoring System Extended equipment: -Cross conveyor belt Automation: -LiftMaster
ManufacturerTrumpf ModelL-3030 Year2003 ObservationsLaser Cutting Trumpf TCL 3030 - 4000W + LiftMaster
Working area: XxYxZ [mm]: 3000x1500x115 mm.
Control: Siemens Sinumerik 840 D Laser-Type: CO2 TLF 4000 turbo
Operating hours: 93.980/69.877h;
Power: 4000W CNC Laser Output [Watt]: 190-4000
Max. Workpiece Weight [kg]: 710
Max. Material Thickness (mild steel) [mm]: 20 Max.
Material Thickness (stainless steel) [mm]: 15 Max.
Material Thickness (aluminum) [mm]: 10 Max.
Positioning Speed [m/min.]: axis-parallel / simultaneous (Х и Y): 60/84
Consumption values laser gas: CO2 - 1,0 l/h; N2 - 6,0 l/h; He - 13,0 l/h Compressed air consumption: 7-9 bar, 31 m3 /h 720 l/min
Electric connection: 33-67 kW / 88 kVA / 400W (± 10%) / 50Hz (± 1%) / 3 Phase / 160 A.
Dimensions machine: L/W/H [mm]: 9800/4600/2000;
Weight [kg]: 11500.
Standard equipment:
-Closed machine frame with integrated laser unit.
-Motion unit for high precision processing.
-Drives with maintenance-free servo motors.
-Enclosed beam delivery system, -Mirror telescope,-Automatic pallet changer, -Conveyor belt for small parts / slug, -TFT colour screen, -Work area lighting,-Machine up to 43 o ambient temperature, -AutoLas Plus -HI-LAS® -PlasmaLine PMS plasma sensor -SprintLine® -ContourLine® -Programmable cutting gas pressure: TRUMPF Laser: -CO2-Laser TLF 4000 turbo, -Radio-frequency excitation, -Laser control TASC, -Laser power control -Logbook function laser Cutting head: -Laser cutting head with 5 zoll lens -Laser cutting head with 7,5 zoll lens -Cutting head quick-change device -Capacitive height regulation (DIAS III) Digitales Intelligentes Abstands-System -Spray Control:- Open control PC-based, simple operation and networking -Online-Help: -Diagnostic functions: -Logbook function -Technology data -Teleservice -Shutdown -Position laser diode -Workshop programming ToPs 100 lite Data transmission: -Network connection -BNC-/ RJ 45 network connector -3.5 Floppy Drive -MDE interface Safety: -CE label: -Light barrier: -Multi chamber exhaust system -Compact dust extractor-Machine enclosure with Macrolon panels -Monitoring System Extended equipment: -Cross conveyor belt Automation: -LiftMaster
Start price 55.000 €
ManufacturerAmada ModelHFE M2 1003 Year2015 Observations
CNC Control NC AB- PAD,
4 Axis (Y1-Y2-X-R, Z1-Z2 Manual) Capacity [kN]: 1000
Bending length [mm]: 3110
Width between columns [mm]: 2705
Throat [mm]: 420 Stroke [mm]: 200
Usable installation height [mm]: 470
Speeds rapid [mm/s]: 100 Return traverse speed [mm/s]: 100 Speeds working [mm/s]: 0-10
Electric connection 9 kW/400V /50 Hz;
L/W/H [mm] 3950/ 1880/ 2685
Weight [kg] 6910
Foot switch with two pedals and panic-stop function Upper tool holder as an intermediate piece with mech. Quick clamping device Electronic handwheel for interactive programming of all axes Lasersystem AKAS
Dimensions3950x1880x2685Weight6910
ManufacturerAmada ModelHFE M2 1003 Year2015 Observations
CNC Control NC AB- PAD,
4 Axis (Y1-Y2-X-R, Z1-Z2 Manual) Capacity [kN]: 1000
Bending length [mm]: 3110
Width between columns [mm]: 2705
Throat [mm]: 420 Stroke [mm]: 200
Usable installation height [mm]: 470
Speeds rapid [mm/s]: 100 Return traverse speed [mm/s]: 100 Speeds working [mm/s]: 0-10
Electric connection 9 kW/400V /50 Hz;
L/W/H [mm] 3950/ 1880/ 2685
Weight [kg] 6910
Foot switch with two pedals and panic-stop function Upper tool holder as an intermediate piece with mech. Quick clamping device Electronic handwheel for interactive programming of all axes Lasersystem AKAS
Dimensions3950x1880x2685Weight6910
Start price 65.000 €
